1U 19" Rackmount Network Application Platform
N15-FT is a standard 1U rack mount network security application product developed based on the autonomous and controllable Phytium FT-2000/quad-core processor, equipped with 2 × DDR4 memory slot, which can adapt to domestic operating systems such as Kylin. The product is applied to communications, enterprises, finance, education, medical treatment and other industries. N15-FT is widely used in the new-generation high-end application delivery and can be widely applied to information security protection such as firewalls, behavior management and audit, VPN, vulnerability scanning, and gatekeepers.
| Item | Description | |
|---|---|---|
| System Configuration | Processor | Phytium FT2000/4 quad-core processor, dominant frequency of 2.6GHz |
| Memory | Dual DDR4 memory slot，supporting up to 32GB | |
| Storage | SATA | 3 x SATA3.0 port, 1 × 3.5-inch hard disk bay |
| MSATA | 1 x MSATA slot | |
| I/O Port | USB | 2 ×USB3.0 port (at front), 2 × USB3.0 pin (built-in) |
| COM | 1 × Console port, 3 × serial Wafer socket (built-in, RS-232 mode) | |
| GPIO | Supports 8-channel digital GPIO interface | |
| Display Port | 1 x VGA port at rear | |
| Network port | Network card chip | Intel® i210 |
| LAN Port Type | 6 x 10/100/1000Mbps RJ-45 port | |
| Expansion Bus | PCIE | 1 x standard PCIE 8X slot |
| ENS | Supports up to 2 x ENS network card expansion slot, and 1 x ENS network card expansion slot can be selected | |
| Matched Motherboard | COM-1502-FT series | |
| Working Environment | Working temperature: 0°C -40°C humidity: 10% ~ 90% (non-condensing state) |
|
| Storage Environment | Storage temperature: -20°C ~ 70°C storage humidity: 10% ~ 90% (non-condensing state) |
|
| Overall Dimensions | 440mm（W）×43.6mm（H）×400mm（D） | |
| Power Supply | 180W ATX single power supply | |
| Operating Systems | Kylin X86, Unity and other Phytium systems. Please refer to the product manual for details | |
| Name | Type | Platform | Version number | Update Date | Size | Download |
|---|---|---|---|---|---|---|
| N15-FT-Product Manual | VariousPlatform | Vol15.0 | 2025-04-29 | 0.09MB | Download 𐃯 |
